LH840 Ceramic – Level Transmitter (Capacitive Ceramic Sensor and Cable)
The LH840 – Ceramic Hydrostatic Level Transmitter comes with a thick film capacitive ceramic diaphragm. The benefit of using a ceramic diaphragm is that it is resistant to build-up of dirt or debris and is extremely resistant to various chemicals. It is also commonly indicated when suspended solids within the medium are a concern.
The LH840-Ceramic is mounted within a 316SS (or PVC used for mediums corrosive to 316SS) cylindrical body houses the electronic module along with the thick film flush mounted ceramic sensing element. The unit comes with a pre-ordered fixed length of vented polypropylene cable and does not have an enclosed housing or process connection.
All of Sitron’s Hydrostatic Level Probes have a 4-20mA (2-wire) output signal, are fully temperature compensated within the stated range and are offered with surge protection. HART communication protocol is also available. Pressure ranges from 0 to 580 PSI (0 to 40 bar) gauge.
Application: Level Measurement of liquids/slurries or liquid mediums with lots of suspended solids
Operating Voltage: 12…30Vdc
Current Consumption: 22mA max.
Output: 4…20mA (2 wire) w/ Hart (optional)
Accuracy: +/- 0.5%
Sensor Material: Capacitive Thick Film Ceramic
Pressure Range: 0 to 40 Bar (Ceramic)
Electrical Connection: Fixed Cable Out
Cable: Polypropylene cable with vent tube
Body Material: 316SS or PVC
Operating/ Compensated Temperature: -10 to +80ºC / -10 to +70ºC
Overpressure: 3 x F.S.
Class Protection: IP68 Sensor
- Easy to install
- Reliable measurement
- Available in several process connections such as: threaded, flange or sanitary (with Housing only)
- HART protocol communication
Depth/level measurements in ground water, deep wells, water towers, rivers, sewage treatment plants and other similar applications.
Calibration Certificate
Material Certificate
Certificate of Origin
